Product Description
Studs for all TracksCaracteristics
- Oversized and pointed tungsten carbide
- Hot-dipped steel and galvanized stud
- Prevents sinking in the tire
- Big tread for good anchoring
- Possibility of installing on thin rubber
- Good durability
- Light
- Easy to install and dismantle
- 24, 100, 150, 200 and 1000 unit packages
- Installation Tool Included
- SS = Shoulder Stud (with shoulder)
- R = Racing (the carbide is pointed)
Safety boots, Snowmobile, Motocross, Enduro, ATV, Mini tractor, Snowblower
Technical Information
- Always pre-drill with 1/16 "drill bit for snowmobile tracks.
- Ease installing and in pre-drilling we are sure we are going to be in the middle of the track and that we are going to go right.
- Add soap on the stud treads for better penetration.
- For a 120'' track, you need about 180 studs
- For 137'' track, you need about 200 studs
- For 144'' track, you need about 250 studs
- For the pattern of a snowmobile track, take the toughest studs.
Kimpex Data:
- Barcode: 779421581268
- Supplier Number: SS-11200R
- Kimpex Catalog Number: 103159
Product Videos
Custom Field
Length 11 mm
Thread diameter 4.5 mm
Unit per package 200
Lock-nuts or nuts included Yes
Backers included No
Model SS11R
Number 103159
