Product Description
Piston and Ring Installation:- Remember never install chrome rings in chrome plated, nikasil or electrofusion cylinders.
- Prior to installation, fit each ring into the cylinder bore and measure the end gap to eliminate the chance of ring butting. Acceptable gap range is .010 to .025. If gap is inadequate, carefully file to the recommended specs. See “Piston Clearance Guide”. Clean and lubricate all moving parts with 10W30 oil.
- Install pistons with the arrow pointing to the exhaust side of the engine (except for few models Polaris where the arrow points toward the magneto side).
- Install circlips carefully without forcing, bending or turning them. Be sure they seat properly in the grooves and position the openings down.
- Install rings onto matching pistons. Lubricate and check to be sure the end gaps can be completely closed around the locating pins.
- Install new base gaskets, compress rings and carefully slide the cylinders down into position. Before installing the cylinder heads, rotate the crankshaft by hand to make sure pistons and rings move freely into cylinder.
Kimpex Data:
- Barcode: 779422161636
- Supplier Number: R09-722
- Kimpex Catalog Number: R09-722
Product Data:
- Compatible Brand:
- Displacement:
- Bore - Standard:
- Bore - Oversize:
- Cylinders:
- Engine type:
- Number: R09-722
Product Videos
Custom Field
Number R09-722
Kimpex-Category Snow (9A)
Make POLARIS
Model 700 EV XC SP Edge
Model 700 XC Edge
Year 2001
Year 2004
Year 2003
Model 800 XC M-10 L/C
Model 800 XC Special Edge M-10 L/C
Model 800 Pro X L/C 121"
Year 2005
Model 800 Classic Touring Edge ES/R L/C 136"
Model 700 XC M-10 L/C
Model Indy 700 XC Special M-10 L/C
Model 700 XC Special Edge M-10 L/C
Year 2002
Model Indy 700 XC Special L/C 121"
Year 1999
Year 2000
Model Indy 700 XC Special Edge M-10 L/C
Model Indy 700 XC L/C 121"
Model 700 XC L/C
Model Indy 700 XC Deluxe R L/C 121"
Year 1997
Model Indy 700 SKS L/C 136"
Model 700 RMK 151" L/C
Model 700 Pro X2 R L/C 121"
Model 700 Pro X R L/C 121"
Model 700 Classic Touring Edge ES/R L/C 136"
Model Indy 600 XC Special L/C 121"
Model Indy 700 XC Special Edge X L/C 121"
Model Indy 700 XC Special Edge L/C 121"
Model Indy 700 SKS Edge L/C 144"
Model Indy 700 RMK Edge L/C 151"
Model Indy 700 RMK Edge L/C 144"
Model Indy 700 RMK Edge L/C 136"
Model Indy 700 Pro X L/C 121"
Model Indy 700 Classic Touring Edge ES/R L/C 136"
Model Indy 700 Classic Edge ES/R L/C 121"
Model 700 RMK Dragon IQ R L/C 155"
Model 800 XC Special Luxury Pkg Edge ES/R 121"
Year 2007
Model 800 XC Special Edge R L/C 121"
Model 800 XC Edge R L/C 121"
Model 800 Switchback R L/C 144"
Model 700 XC Special Luxury Pakage Edge ES/R 121"
Model 700 XC Special Edge R L/C 121"
Model 700 XC Edge R L/C 121"
Year 1998
Model 700 SKS L/C 136"
Model 700 Switchback R L/C 144"
Model 700 RMK Edge R L/C 151"
Model 700 RMK Edge R L/C 144"
Model Indy 700 RMK L/C 144"
Model Indy 700 RMK L/C 136"
Model Indy 700 Classic ES/R L/C 121"
Model 600 Switchback R L/C 144"
Model 700 Classic Edge ES/R L/C 121"
